Introduction
The Fully Automatic Washing Extracting Machine is a microcomputer-controlled, freestanding solution with 30 programs, designed for efficient washing and extracting. Featuring a stainless steel drum and a full suspension shock structure, it ensures durability and maximum vibration absorption for commercial laundry operations. The Automatic Washing Extracting Machine is ideal for hotels, hospitals, and industrial laundries, handling large volumes of bed sheets, towels, and uniforms. Its frequency-controlled motor and dual heating options make it versatile for various fabric types and settings.
Key Features
- Automated Operation: The Washing Extracting Machine includes a microcomputer with 30 programs for precise control.
- Durable Build: Features a stainless steel inner drum and outer panel for a long service life.
- Safety and Stability: Equipped with a pneumatic lock system and dynamically balanced drums (gravity deviation ≤20g).
- Energy Flexibility: Supports electric, steam, or combined heating for efficient operation.
Technical Specifications
- Control: Microcomputer with 30 programs
- Installation: 100% freestanding, no foundation required
- Drum and Panel: Stainless steel (AISI304)
- Motor: Frequency-controlled
- Safety: Pneumatic lock system
- Balance: Drums tested with ≤20g gravity deviation
- Suspension: Full shock structure with absorbers and springs
- Lubrication: Built-out bearing system for easy maintenance
- Heating Options: Electricity, steam, or both
| Washing Capacity (Kg) | 120 | 130 | 150 |
| Forward tilting angle (degree) | 25° | ||
| Drum Dimension (mm) | Φ1300*900 | Φ1300*1030 | Ф1470*890 |
| Drum volume (L) | 1190 | 1360 | 1510 |
| Washing speed (r/min) | 42 | ||
| High extract speed (1-4) (r/min) | 330/510/540/643 | 330/510/540/643 | 310/480/508/604 |
| Rated Voltage (V) | 220/240/380/400/415/440 | ||
| Motor Power (kw) | 11 | 18.5 | |
| Inverter Power (kw) | 15 | 18.5 | 22 |
| Electric Heating Power (kw) | 48 | 48 | 72 |
| Steam consumption (kg/h) | 60 | 65 | 75 |
| Steam pressure (Mpa) | 0.3-0.6 | 0.3-0.5 | |
| Dimension (L.W.H) | 1900x2560x2100 | 1900x2700x2100 | 2100x2600x2300 |
| Weight | 5000 | 5800 | 6500 |
Why Choose the Fully Automatic Washing Extracting Machine?
The Washing Extracting Machine offers reliability with its robust design, easy maintenance, and advanced automation. Its full suspension system, safety features, and flexible heating options make it a top choice for laundry professionals seeking efficiency and performance.
