Overview
The GEMECH Steam Heated Tumble Dryer is a high-performance industrial drying machine designed for textile mills, garment factories, commercial laundries, hotels, and hospitals. Utilizing an advanced steam heating system, it provides fast, uniform, and energy-efficient drying while maintaining fabric quality. Its heavy-duty construction and intelligent control system ensure reliable performance for continuous industrial operation.
Steam Heated Tumble Dryer
Steam Heated Tumble Dryer With Steam Injection & Steam Spray System For use in hotel, hospital and laundry plant, and textile, jeans, denims, fabrics, wools and garment factory etc..
- Stainless steel drum and frame made of high-quality plate, or full stainless steel
- By steam heating.
- Full-automatic drying.
- High efficiency, low consumption, low noise and safety, and used widely in the field, such as hotel, restaurant, laundry house, water washing plant, and laundry equipment for garment, fabric, apparel
- Its capacity is from 10kg to 180kg.
- CE and ISO9001 certificates.
Machine Configuration
- Inner cylinder: 304 stainless steel
- Steam nozzle: 304 stainless steel
- Housing: cold-rolled steel plate paint
- Control: computer board
Application
Suitable for:
- Textile Dyeing & Finishing Mills
- Garment Manufacturing
- Commercial Laundry Plants
- Hotels & Hospitals
- Denim & Washing Plants
Ideal for drying cotton, polyester, denim, linen, wool, towels, knitted fabrics, woven fabrics, & blended textiles.
Features
- Steam heating for fast and uniform drying
- Heavy-duty stainless-steel drum
- PLC touch-screen control system
- Energy-efficient with low steam consumption
- Low noise and stable operation
- Automatic temperature and drying time control
- Industrial safety protection system
- Easy maintenance and long service life
Technical Parameter
| Model | Capacity (Kg) | Drum Dimension (mm) | Speed (r/min) | Power (kW) | Overall Dimension (mm) | Steam Pressure (MPa) |
| ZTD-10 | 10 | 640×650 | 46 | 1.1 | 700×1100×1340 | 0.4-0.6 |
| ZTD-15 | 15 | 760×560 | 35 | 1.5 | 900×1200×1500 | 0.4-0.6 |
| ZTD-30 | 30 | 950×860 | 32 | 2.2 | 1100×1450×1900 | 0.4-0.6 |
| ZTD-50 | 50 | 1160×1000 | 32 | 3.0 | 1320×1700×2300 | 0.4-0.6 |
| ZTD-70 | 70 | 1260×1000 | 30 | 3.0 | 1400×1700×2300 | 0.4-0.6 |
| ZTD-100 | 100 | 1320×1100 | 30 | 4.4 | 1500×1800×2390 | 0.4-0.6 |
| ZTD-120 | 120 | 1500×1080 | 28 | 5.2 | 1620×1850×2410 | 0.4-0.6 |
| ZTD-150 | 150 | 1600×1160 | 27 | 7.4 | 1740×1900×2550 | 0.4-0.6 |
| ZTD-180 | 180 | 1800×1100 | 27 | 8.4 | 1850×2000×2600 | 0.4-0.6 |
Why Choose GEMECH Steam Heated Tumble Dryer?
Choose the GEMECH Steam Heated Tumble Dryer for reliable, efficient, and fabric-friendly industrial drying. Its steam heating system delivers uniform heat and helps shorten drying cycles, while the stainless-steel inner cylinder supports long-term durability and hygiene. Automatic temperature and drying-time control simplify operation and improve drying consistency across different textile loads. The machine also combines low steam consumption, low noise, and stable performance to help reduce operating costs. Its heavy-duty construction suits demanding textile mills, garment factories, commercial laundries, hotels, hospitals, and denim washing plants. With models ranging from 10 kg to 180 kg, GEMECH provides a suitable solution for different production requirements. Easy maintenance, industrial safety protection, and dependable control technology further make this dryer a practical choice for continuous professional use.
